DESCRIPTION

Ideal for automating the analysis of Anaplasma, Cymurro, Leishmania, Parvovirus, FIV, FeLV, and Filaria.
Stratego handles up to three 96-well microplates as independent sessions: + 1 additional fourth plate for predilution that can be converted into a working plate.
The analyzer handles up to 4 different methods with one sample.
Samples are loaded via front slides and identified with barcodes, perfect for creating a simplified work list. The sampling device is equipped with a pressure sensor for detecting bubbles, clots and draught level.
The instrument is supplied with a PC and dedicated software that can be interfaced with the LIS and managed remotely thanks to Futurlab's technical support.

No cross-contamination!

Stratego prevents any contamination or entrainment because:
It is the only analyzer to use non-conductive disposable tips for sample dispensing - later automatically discarded in the front drawer.
Its washing comb has 8 dedicated needles for dispensing and 8 for aspirating. They are height-adjustable for total precision of the washing phase.
Thanks to these features, there is no need for pre- or post-analysis cleaning.

The innovatively designed plate holder frames make it compatible with all plates on the market. They also adjust the height of the plate and the lowering of the dispensing needles, ensuring drying precision.

Instant

The instrument is equipped with a lateral LED indicator light: BLUE for stand-by, GREEN for working and RED to indicate a problem.
The special design with compact front discharge canisters with level sensors ensures your work will not be interrupted.

TECHNICAL FEATURES

• Up to 320 disposable tips
• Photometer with 8 frequency LEDs for each wavelength and optical filters: 4 wavelengths, 2 standard and 2 optional
• Barcode reader for samples and reagents
• 3 washer canisters, 1 water and 1 discharge canister
• Washer module consisting of 3 plates, 3 incubators with independent shakers and a 16-pin manifold
• Hardware and software designed entirely in Italy
• Size 83x94.5x69.5 cm
• Weight: 100kg
